Siemens SIMATIC HMI series User Manual

Technical specifications
11.10 Connection box compact interfaces
Mobile Panels 2nd Generation
Operating Instructions, 09/2018, A5E33876626-AC
245
11.10.3
Plug-in terminal strip X10
Plug-in terminal strip, 12-pin
Contact
Assignment
Associated circuits and reference information
1
Functional grounding
Ground and power supply
See "Connecting the functional grounding and power
supply to the connection box (Page 64)."
2 M
3
P24
4
Not connected
5
ENABLE2–
Enabling button
See section "Operating the enabling button (Page 81)"
and wiring information in the following section
6
ENABLE1+
7
ENABLE1–
8
ENABLE2+
9
STOP 24
Emergency stop / stop button
See section "Pressing the emergency stop / stop
button (Page 83)" and wiring information in the
following section
10
STOP 23
11
STOP 14
12
STOP 13

Siemens SIMATIC HMI series Specifications

General

Series	SIMATIC HMI
Category	Control Panel
Display Type	TFT LCD
Touch Screen	Yes (resistive or capacitive, depending on model)
Processor	Varies by model (e.g., ARM-based processors)
Storage	Varies by model (e.g., Flash memory, microSD card slot)
Communication Interfaces	Ethernet, USB
Protection Class	IP65 (front panel), depending on model
Operating Temperature	0 to 50°C, -20 to 60°C
Power Supply	24 V DC
Memory	128 MB, 256 MB
