Parameterizing the Mobile Panel
5.13 Configuring network operation
Mobile Panels 2nd Generation
140 Operating Instructions, 09/2018, A5E33876626-AC
Example: The IP address of the device on which the Sm@rtServer was started is
"192.168.0.1", and port 5800 is set on the Sm@rtServer.
● Example of call via Internet Explorer: "http://192.168.0.1:5800".
● Example of call via the Sm@rtClient application: "192.168.0.1".
Application examples Mobile Panels 2nd Generation
(https://support.industry.siemens.com/cs/ww/en/ps/14746/ae
)
You can use this option to configure the HMI device as HTTP server. You can then view the
HTML pages of the server HMI device using a Web browser or access the tags of the server
HMI device using the "SIMATIC HMI HTTP Protocol". Read or write access to the tags is
possible, depending on the parameter assignment of the Web Server.
● The Web Server is a component of the Sm@rtServer option. For HMI devices with an
image that is compatible with WinCC (TIA Portal) prior to V14, the following applies: The
HMI device has a Sm@rt Server license that was transferred to the HMI device via the
Automation License Manager. Starting with WinCC (TIA Portal) V14, the Sm@tServer
option for Comfort Panels is license-free.
● The HMI device has a project that was compiled with one of the following options in the
Runtime settings of the HMI device under "Runtime settings > Services":
– "HTML pages"
– "HTTP channel server"
– "Web Service SOAP"
● The Control Panel is open.
● Your system administrator has provided you with the necessary information for parameter
assignment of the Web Server.
Note
The "Web Server" tab is only available if the HMI device has a project that was compiled with
one of the three Runtime settings listed under "Requirements".
Additional tabs may appear in the "WinCC
Internet Settings" dialog. This depends on the
options that have been enabled for operating the local network in the project.
