Parameterizing the Mobile Panel
5.14 Assigning a safety-related operating mode
Mobile Panels 2nd Generation
142 Operating Instructions, 09/2018, A5E33876626-AC
11. In the "Authorizations" tab you specify the Web authorizations. To use the SIMATIC
HTTP server, the user must have the Web authorization "RTCommunication".
12. Save the settings using "Apply" and close the dialog box with "OK".
13. Press the "Start Web-Server" button to start the Web Server on the HMI device.
Use the "Close Web-Server" button to close Web Server.
14. Close the dialog with "OK".
When the Web Server is started, you can use a Web browser to access the service pages
available on the HMI device by default, additional pages you have configured yourself or
other Internet pages. You can access the tags of the server HMI device with a client via a
configured HTTP connection.
Additional information on configuration, types of access and certificates is available in the
TIA information system under:
"Visualize processes > Options > WinCC Sm@rtServer".
Assigning a safety-related operating mode
This section applies only to fail-safe Mobile Panels and describes how to assign failsafe
mode to a connection box.
You make the following specifications for each connection box by selecting the operating
mode:
● Function of the emergency stop / stop button: "Emergency stop" or "Stop"
● Type of the F-system: Hardwired F-system or PROFIsafe-based F-system
Read "Important information on emergency stop / stop button (Page 39)".
The table below shows which F-system can be implemented depending on the connection
box used and what modes you can use in the corresponding F-system.
without
emergency stop / stop
bypass
with
emergency stop / stop
bypass
advanced Feasible – Feasible
Possible
operating mode
E-stop button
evaluated by
PROFIsafe
Stop button evaluated by
Stop button evaluated by
E-stop button evaluated by
E-stop button evaluated by
