A.3 Parameterization of the connection box standard and
connection box advanced
Mobile Panels 2nd Generation
Operating Instructions, 09/2018, A5E33876626-AC
269
Parameterization of the connection box standard and
connection box advanced
The connection box standard and the connection box advanced have an internal
SCALANCE switch. You parameterize the two connection boxes using the "Web Based
Management" WBM of the respective SCALANCE switch as described in the following
document:
Configuration manual "SCALANCE X-200"
(https://support.industry.siemens.com/cs/ww/de/view/109476763
)
The description in the manual includes the following topics, among others:
● WBM login, that is login for parameter assignment of the connection box
● Firmware update
● Diagnostics
● Additional configuration options
System events on the HMI device provide information about internal states of the HMI device
and the controller.
Note
System events are only indicated if an alarm window was configured. System events are
output
in the language currently set on your HMI device.
System events may contain encrypted parameters which are relevant to troubleshooting
because they provide a reference to the source code of the runtime software. Encrypted
parameters are output after "Error code:".
Description of the system events
A list of system events and their description is available in the information system of the TIA
Portal.
