Siemens SIMATIC HMI series User Manual

Operating a project
8.7 Closing the project
Mobile Panels 2nd Generation
208 Operating Instructions, 09/2018, A5E33876626-AC
An infotext that is available for an operating object is displayed with the <Help> key on the
screen keyboard. Depending on the configuration, infotext may also be accessed with an
operating object. Please refer to your system documentation for additional information.
Requirement
● Operating element with configured infotext is selected.
Procedure
1. Press the <HELP> key.
The infotext for the screen or operating object is displayed.
Note
The configuration engineer can configure infotext for an I/O field and the associated
screen. You can switch between two infotexts by touching the infotext window.
2. Close the window with the infotext.
8.7
Closing the project
Procedure
1. Use the corresponding operator control object to close the project.
The following only applies to fail-safe Mobile Panels: When PROFIsafe communication is
active, the "Confirm logoff" dialog is displayed. Confirm the logoff in the corresponding
dialog.
2. Wait for the Start Center to be displayed.
3. Pull out the connecting cable if required, as described in section
"Unplugging the connecting cable (Page 211)".

Siemens SIMATIC HMI series Specifications

General

Series	SIMATIC HMI
Category	Control Panel
Display Type	TFT LCD
Touch Screen	Yes (resistive or capacitive, depending on model)
Processor	Varies by model (e.g., ARM-based processors)
Storage	Varies by model (e.g., Flash memory, microSD card slot)
Communication Interfaces	Ethernet, USB
Protection Class	IP65 (front panel), depending on model
Operating Temperature	0 to 50°C, -20 to 60°C
Power Supply	24 V DC
Memory	128 MB, 256 MB
