Siemens SIMATIC HMI series User Manual

Technical specifications
11.8 Technical specifications
Mobile Panels 2nd Generation
234 Operating Instructions, 09/2018, A5E33876626-AC
Memory
KTP400F Mobile
KTP700 Mobile
KTP700F Mobile
KTP900 Mobile
KTP900F Mobile
Data memory
512 MB
Program memory 1024 MB
Interfaces
KTP400F Mobile
KTP700 Mobile
KTP700F Mobile
KTP900 Mobile
KTP900F Mobile
1 × Ethernet RJ45
10/100 Mbps
1 x USB 2.0 Type A, max. 500 mA
Power supply, via connection box
KTP400F Mobile
KTP700 Mobile
KTP700F Mobile
KTP900 Mobile
KTP900F Mobile
Rated voltage
+24 V DC
Permitted voltage range
19.2 … 28.8 V (24 V ± 20%)
Transients, maximum permitted
35 V (500 ms)
Time between two transients
≥ 50 s
Current consumption, typical
Approx. 250 mA
Approx. 350 mA
Approx. 450 mA
Continuous current, maximum
Approx. 400 mA
Approx. 440 mA
Approx. 500 mA
Inrush current I
2
t
Approx. 0.2 A
2
s
Fuse, internal
Electronic
Bypass period after the HMI device has
been disconnected from the connection
box
None 5 minutes
Charging time on the connection box
until the bypass period is guaranteed
Not applicable 2 minutes
Miscellaneous
KTP400F Mobile
KTP700 Mobile
KTP700F Mobile
KTP900 Mobile
KTP900F Mobile
Real time clock, buffered, can be
synchronized
Yes, typical buffer period 3 weeks
Feedback, acoustic
No

Siemens SIMATIC HMI series Specifications

General

Series	SIMATIC HMI
Category	Control Panel
Display Type	TFT LCD
Touch Screen	Yes (resistive or capacitive, depending on model)
Processor	Varies by model (e.g., ARM-based processors)
Storage	Varies by model (e.g., Flash memory, microSD card slot)
Communication Interfaces	Ethernet, USB
Protection Class	IP65 (front panel), depending on model
Operating Temperature	0 to 50°C, -20 to 60°C
Power Supply	24 V DC
Memory	128 MB, 256 MB
