Parameterizing the Mobile Panel
5.15 Functions for service and commissioning
Mobile Panels 2nd Generation
Operating Instructions, 09/2018, A5E33876626-AC
153
5. Press the "Next" button. The projects that are located on the external storage medium are
displayed in the following dialog. The following figure shows an example.
6. Select the project that you want to load into the HMI device. Press the "Details" button to
receive additional information about the selected project.
7. Press the "Next" button. The HMI device checks whether the project data can be loaded.
The result of the check is displayed in the "Load Preview" dialog.
The following messages can be displayed in the "Load Preview" dialog:
– Alarms of type "Information":
Icon
Status
Alarm
Meaning
Info
Firmware version ...
Runtime version ...
Firmware and Runtime version on the HMI device
Info Ready For Loading Project data is suitable for the HMI device
– Alarms of type "Warning" with options:
Icon
Status
Alarm
Meaning
Overwrite
Select project
data
The following lines contain options for overwriting data
on the HMI device.
Recipes
Overwrite recipes of the HMI device with the recipes of
the project (optional).
User
administration
data
Overwrite the user administration on the HMI device with
the user administration of the project (optional).
