Siemens SIMATIC HMI TP1000F Mobile RO - Page 138

Using a client
6.2 Connect client
TP1000F Mobile RO
138 Operating Instructions, 08/2017, A5E39831415-AA
Note
The length of time you need to press the touch screen before the RemoteOper
ate toolbar is
displayed is defined in the "roServer.ini" file.
The special functions of the RemoteOperate toolbar are shown in the table below:
Buttons
Functions
Executes a right-click on the server.
Proceed as follows:
1. Select a screen object which has a right-click function.
2. Touch the "Right-click" button.
3. Execute the desired function.
Opens the screen keyboard (only with the Windows CE operating system).
Operates the Windows button on the server.
Executes the <Ctrl+Alt+Del> shortcut on the server, e.g., to log onto the server.
Terminates the connection to the server.
Closes the RemoteOperate toolbar.
Opens the alarm window: Alarm is pending.
Button disabled: No alarm is pending.
See also
Creating/editing a server selection list (Page 131)
