Siemens SIMATIC HMI TP1000F Mobile RO User Manual

Technical specifications
9.7 Technical specifications
TP1000F Mobile RO
Operating Instructions, 08/2017, A5E39831415-AA
173
9.7.6
Specification of cables to be used
Cables for 24 V DC and functional grounding
Connection box
advanced
Connection box
standard
Connection box
compact
Connectable cable cross-sections for single-
core/solid cables H05(07) V-U
0.5 ... 1.5 mm²; AWG 21 ... AWG 16
Connectable cable
cross-sections for
flexible/stranded
cables
H05(07) V-K
Without ferrule 0.5 ... 1.5 mm²
AWG 21 ... AWG 16
With ferrule according to
DIN 46 228/1
0.5 ... 1.5 mm²
With ferrule according to
DIN 46 228/4
0.5 ... 0.75 mm²
Number of cables per connection
1
Stripped length of the cables
8 mm
Connection technology
Push-in terminal
Connections for emergency stop / stop button
and enabling button
Connection box
advanced
Connection box
standard
Connection box
compact
Connectable cable cross-sections for single-
core/solid cables H05(07) V-U
0.2 ... 1.5 mm²; AWG 24 ... AWG 16
Connectable cable
cross-sections for
flexible/stranded
cables
H05(07) V-K
Without ferrule
0.2 ... 1.5 mm²
AWG 24 ... AWG 16
With ferrule according to
DIN 46 228/1
0.25 ... 1.5 mm²
With ferrule according to
DIN 46 228/4
0.25 ... 0.75 mm²
Number of cables per connection
1
Stripped length of the cables
8 mm
Connection technology
Push-in terminal
PROFINET cables
Connection box
advanced
Connection box
standard
Connection box compact
Connectable cable 6XV1840-2AH10 or comparable 6XV1840-2AH10 or
comparable, Industrial Ethernet
FastConnect Cable 2x2 *
Connection technology
Fast connect
RJ45
* Available on the Internet at: Industrial Ethernet FastConnect Cable 2x2
(
http://w3.siemens.com/mcms/industrial-communication/en/ie/Cabling-technology/fc-cable-
2x2/Pages/fc-cable-2x2.aspx)
