Installing system components
3.6 Connecting the connection box
TP1000F Mobile RO
Operating Instructions, 08/2017, A5E39831415-AA
61
3.6.7
Setting the box ID of the connection box
You need to set a box ID for each connection box. The box ID must be valid and is
transferred to the RemoteOperate Server. The server can identify the client using the box ID.
Note
You need to set a box ID for each connection box. Do not assign the same box ID twice.
Note
Changing the box ID of a connection box
Observe the following informati
on when changing the box ID of a connection box:
•
If you want to change the box ID of a connection box, remove the connection box from its
power supply before you set the box ID with the rotary coding switch.
•
After you have confirmed the changed box ID in the dialog "Safety operation", unplug the
HMI-device connecting cable from the connection box and then plug it into the connection
box again.
Rotary encoder switch
● Position of the rotary coding switch in the connection box compact
● Position of the rotary coding switch in the connection boxes standard and advanced
