Parameterizing the Mobile Panel
5.7 General settings
TP1000F Mobile RO
Operating Instructions, 08/2017, A5E39831415-AA
99
5.7.8
Displaying general system properties
Use this function to display the general system information relating to the operating system,
processor and memory. You will need this information when contacting Technical Support
(Page 184).
Requirement
The Control Panel is open.
Procedure
● Open the "System Properties" dialog using the "System" icon.
The following figure shows an example.
①
Information on the version and the copyright of the operating system
②
Processor information
③
Information on the size of the RAM
The displayed data relates to the specific device. The processor and memory information
may deviate from that for this HMI device.
5.7.9
Displaying information about the Mobile Panel
You can use this function to display device-specific information. You will need this
information if you contact Technical Support (https://support.industry.siemens.com
).
Requirement
You have opened the "Device" tab in the "OP Properties" dialog with the "OP" icon.
