Installing system components
3.5 Connecting the Mobile Panel
TP1000F Mobile RO
Operating Instructions, 08/2017, A5E39831415-AA
49
Procedure
Removing the SD memory card
1. Grab the SD memory card with an appropriate tool.
2. Pull the SD memory card from the slot to the center of the terminal compartment.
Inserting a new SD memory card
1. Turn the SD memory card so that the contacts are pointing towards the motherboard.
2. Push the SD memory card into the slot with the appropriate tool.
3. Attach the connecting cable to the Mobile Panel.
4. Close the terminal compartment cover.
5. Fasten the retainer.
6. Connect the Mobile Panel to a connection box.
When the "Use system card?" dialog appears on the display, confirm the message.
Inserting the USB memory stick
The USB port is used to transfer data and save specific HMI device data.
USB port only enabled for USB flash drive
The USB port is only enabled for use with a USB flash drive for commissioning and
maintenance purposes.
IP65 degree of protection with a USB flash drive not guaranteed
When a USB flash drive is connected to the USB port, the Mobile Panel does not conform
to an IP65 degree of protection.
Do not connect a USB device if dust or moisture can enter the HMI device.
● An industrial-grade USB flash drive
1. Remove the cover cap of the USB port.
2. Insert the USB flash drive into the slot.
Storage media (Page 20)
Functions for service and commissioning (Page 117)
