5.12 Assigning a safety-related operating mode
TP1000F Mobile RO
Operating Instructions, 08/2017, A5E39831415-AA
115
5.12
Assigning a safety-related operating mode
This section describes how to assign failsafe mode to a connection box.
You specify the function of the emergency stop/stop button for each connection box by
selecting the operating mode:
● "Emergency stop" or
● "Stop"
Read "Important information on emergency stop / stop button (Page 31)".
The table below shows which F-system can be implemented depending on the connection
box used and what modes you can use in the corresponding F-system.
Connection box
Hardwired F-system
without
emergency stop / stop
bypass
with
emergency stop / stop
bypass
compact
Feasible
–
standard
Feasible
–
advanced – Feasible
Possible operating
mode
Stop button evaluated by safety relay
Stop button evaluated by safety relay
E-stop button evaluated by safety
relay
E-stop button evaluated by safety
relay
