Parameterizing the Mobile Panel
5.5 Control Panel
TP1000F Mobile RO
78 Operating Instructions, 08/2017, A5E39831415-AA
Updating the HMI device image (ProSave) (Page 125)
Using automatic backup (Page 127)
Displaying general system properties (Page 99)
Displaying memory distribution (Page 95)
Specifying the computer name of the HMI device (Page 112)
Configuring transfer (Page 94)
Setting the delay time (Page 96)
Operating the Control Panel
You can operate the Control Panel using the touch screen. The following steps give a
general description of how to operate a function.
● The RemoteOperate Client software was closed.
● The Start Center is displayed.
1. Open the Control Panel using the "Settings" button.
2. Double-click an icon. The corresponding dialog is displayed.
3. Select a tab.
4. Make the desired settings. When you navigate to an entry field, the screen keyboard
opens.
5. Your settings are applied with the button.
To cancel the entry, press the button. The dialog closes.
6. To close the Control Panel, use the button.
7. Start the RemoteOperate Client software with the "Start" button.
The Start Center is displayed.
Configuring the screen keyboard (Page 82)
