Installing system components
3.5 Connecting the Mobile Panel
TP1000F Mobile RO
48 Operating Instructions, 08/2017, A5E39831415-AA
6. Plug the connector into port X80. Note the mechanical coding on the connector.
7. Plug in the RJ45 connector at port X1. Make sure that the connector audibly engages.
8. Place the terminal compartment cover over the terminal compartment. Tighten the
corresponding screws using a torque of 0.2 Nm.
When closing the terminal compartment cover, make sure that the corresponding seal
is undamaged and properly seated. Degree of protection IP65 is otherwise not
guaranteed.
Make sure that the cables in the terminal compartment are not bent too much.
When closing the terminal compartment cover, be careful not to trap the cables.
9. Attach the retainer.
Connecting the Mobile Panel connecting cable (Page 45)
Replacing an SD memory card
All Mobile Panels 2nd Generation, with the exception of the KTP400F Mobile, have a slot for
an optional SD memory card.
Note
Use only a SIMATIC HMI Memory Card
Use only a SIMATIC HMI Memory Card with the Mobile Panel.
Unsuitable tools may damage the Mobile Panel
To avoid damaging the motherboard of the Mobile Panel, insert or remove the SD memory
card with an appropriate tool made of plastic.
● The Mobile Panel is deenergized.
● The terminal compartment is open.
● The connecting cable is removed.
● You have taken precautions to protect your device, see section "Connection information
(Page 43)".
● A suitable tool made of plastic for gripping the SD memory card
● Phillips screwdriver, size 2
