Technical specifications
9.4 Mechanical ambient conditions
TP1000F Mobile RO
Operating Instructions, 08/2017, A5E39831415-AA
159
9.3.2
Emitted interference
The HMI device meets the requirements of EN 61000-6-4. The HMI device complies with
limit class A.
The connection boxes meet the requirements of EN 61000-6-4. The HMI device complies
with limit class A.
Note
The HMI device
and connection boxes are not designed for use in residential areas.
Operation of an HMI device and connection box in a residential area can interfere with radio
and TV reception.
9.3.3
Immunity to interferences
The HMI device meets the requirements of EN 61000-6-2.
The connection boxes meet the requirements of EN 61000-6-2.
9.4
Mechanical ambient conditions
9.4.1
Transport and storage conditions
The following information applies to an HMI device and connection box transported and
stored in its original packaging.
The HMI device meets the requirements of IEC 60721-3-2, Class 2M2 with the following
amendments and limitations:
Type of condition
Permitted range
Free fall
≤ 1 m
Vibration to IEC 60068-2-6 5 … 8.4 Hz, deflection 3.5 mm
8.4 … 500 Hz, acceleration 1 g
Shock to IEC 60068-2-27
250 m/s
2
, 6 ms, 1000 shocks
9.4.2
Operating Conditions
The HMI device is designed for mobile operation in a location protected from the weather.
The HMI device meets the requirements of IEC 60721, Class 3M3 with the following
amendments and limitations:
The following information applies to the HMI device and to the connection box.
Type of condition
Permitted range
Vibration to IEC 60068-2-6 5 ... 8.4 Hz, deflection 3.5 mm
8.4 ... 200 Hz, acceleration 1 g
Shock to IEC 60068-2-27
150 m/s
2
, 11 ms, 3 shocks
Free fall tested to IEC 60068-2-31, knocking
tested over according to IEC 60068-2-31
1.2 m free fall
