Parameterizing the Mobile Panel
5.6 Configuring operation
TP1000F Mobile RO
86 Operating Instructions, 08/2017, A5E39831415-AA
4. Touch the center of the calibration cross until it is shown at the next position. The
calibration cross appears at four other positions.
Once you have touched the calibration cross at all positions, the following dialog appears:
5. Touch the touch screen within the indicated time.
The calibration will be saved. The "Touch" tab is displayed once again in the "OP
Properties" dialog. If you do not touch the touch screen within the time shown, your
original setting will be retained.
6. Close the "OP Properties" dialog with "OK".
The touch screen of the HMI device is calibrated.
Restarting the HMI device
You need to perform a restart in the following situations:
● You have changed the time zone and activated daylight saving time, see section "Setting
the date and time (Page 89)".
● You have changed the settings for the screensaver, see section "Setting the screen saver
(Page 92)".
All volatile data is lost with a restart.
Make sure that the RemoteOperate Client software is closed and no data is being
written to the flash memory.
