Technical specifications
9.7 Technical specifications
TP1000F Mobile RO
166 Operating Instructions, 08/2017, A5E39831415-AA
Interfaces
TP1000F Mobile RO
1 × Ethernet RJ45
10/100 Mbps
USB 2.0 Yes
Power supply, via connection box
TP1000F Mobile RO
Rated voltage
+24 V DC
Permitted voltage range 19.2 … 28.8 V (24 V ± 20%)
Transients, maximum permitted
35 V (500 ms)
Time between two transients ≥ 50 s
Current consumption, maximum
Approx. 830 mA
Current consumption, typical
Approx. 450 mA
Inrush current I
2
t
Approx. 0.2 A
2
s
Fuse, internal
Electronic
Bridging time after the HMI device has been disconnected from
the connection box
5 minutes
Charging time on the connection box until the bridging time is
guaranteed
2 minutes
Miscellaneous
TP1000F Mobile RO
Real time clock, buffered, can be synchronized
Yes, typical buffer period 3 weeks
Feedback, acoustic
No
Insulation testing, protection class and degree of protection
Insulation testing
The insulation strength is demonstrated in the type test with the following test voltages in
accordance with IEC 61131-2:
Circuits with rated voltage of U
i
Test voltage
< 50 V
500 V AC to other circuits / to ground
Protection class
Protection class III according to IEC 61131-2.
