Technical specifications
9.7 Technical specifications
TP1000F Mobile RO
168 Operating Instructions, 08/2017, A5E39831415-AA
Power supply
The information in the table below applies to all connections boxes.
Rated voltage +24 V DC
Permitted voltage range
19.2 … 28.8 V (± 20 %)
Transients, maximum permitted
35 V (500 ms)
Time between two transients
≥ 50 s
Enabling button
1
Supply voltage
24 V DC
Amperage, max.:
300 mA
Amperage, min.:
10 mA
Emergency stop/stop button
1
Supply voltage
24 V DC
Amperage, max.:
500 mA
Amperage, min.:
10 mA
Cable length between connection box and PLC
≤ 30 m
Fuse, internal
Electronic
Current load PLC-accompanying signals
< 100 mA
Recovery time
≥ 1 s
1
For fail-safe Mobile Panel
Current consumption of the connection box compact
Current consumption without
Mobile Panel
Typical
Approx. 20 mA
Continuous current, maximum
Approx. 50 mA
Inrush current I
2
t
Approx. 0.1 A
2
s
Current consumption with Mo-
bile Panel
Typical
Approx. 550 mA
Continuous current, maximum
Approx. 700 mA
Inrush current I
2
t
Approx. 0.6 A
2
s
Current consumption of the connection box standard and connection box advanced
Current consumption without
Mobile Panel
Typical Approx. 100 mA
Continuous current, maximum
Approx. 150 mA
Inrush current I
2
t Approx. 0.5 A
2
s
Current consumption with Mo-
bile Panel
Typical
Approx. 600 mA
Continuous current, maximum
Approx. 750 mA
Inrush current I
2
t
Approx. 0.6 A
2
s
Industrial Ethernet switch
Designation
SCALANCE XF208
Article number
6GK5208-0BA00-2AF2
Internal switches of the connection box standard and connection box advanced
Industrial Ethernet switch of the
connection box standard
Designation
SCALANCE XF208
Article number
6GK5208-0BA00-2AF2
Industrial Ethernet switch of the
connection box advanced
Designation
SCALANCE XF204 IRT
Article number
6GK5204-0BA00-2BF2
