Siemens SIMATIC HMI TP1000F Mobile RO User Manual

Technical specifications
9.7 Technical specifications
TP1000F Mobile RO
Operating Instructions, 08/2017, A5E39831415-AA
171
Reaction times
The table shows below the reaction times of the HMI device up to the output or interface X10
of the connection box, dependent on the F-system.
Operating mode
Stop/E-stop button evaluated
by safety relay
Reaction time
Emergency stop / stop button
Reaction time during error-free
operation
Press switch
< 10 ms
Unlock switch < 10 ms
Reaction time with error
Discrepancy detected (safe state)
See Safety relay
Critical internal error
< 30 ms
Discrepancy time
See Safety relay
Acknowledgment time in safety mode
–
Enabling
Reaction time during error-free
operation
No Enabling or Panic
< 15 ms
Enabling
< 40 ms
Reaction time with error pending
Discrepancy detected (safe state)
< 15 ms
Critical internal error
< 30 ms
Discrepancy time
500 ms
Acknowledgment time in safety mode
-
Note
Times
The specified times do not include the applicable safety relay.
Safety characteristics
Note
All values for the following information are based on the SN 29500:2005 and an ambient
tempe
rature of 60 °C.
