Installing system components
3.6 Connecting the connection box
TP1000F Mobile RO
54 Operating Instructions, 08/2017, A5E39831415-AA
①
Ground connection
②
Equipotential bonding conductor, cross-section 1.5 mm
2
③
Equipotential busbar
④
PROFINET cable
⑤
Equipotential bonding conductor, cross-section ≥ 16 mm
2
⑥
Parallel routing of the equipotential bonding conductor and data cable
⑦
Cable clip
⑧
Control cabinet
