6.10 Linear motors (1FN1 and 1FN3 motors)
6-168
 Siemens AG 2000 All Rights Reserved
SINUMERIK 840D Installation and Start-Up Guide (IAD) – 04.00 Edition
Note
The outer and inner shield of the signal leads in the power cable and the shield
of the temperature sensor coupling lead must be attached in a 360° connection
with the shield connection plate.
Failure to connect the shield correctly can result in high touch voltages, mal-
functions and sporadic errors or irreparable damage to the closed-loop control
module.
Table 6-23 Assignments of temperature sensor coupling lead
Signal Power cable Temperature sensor coupling lead
(dongle)
–X411
on drive
Temperature sensor + Black core Brown + black cores Pin 13
Temperature sensor – White core Orange + red cores Pin 25
Temperature switch/PTC Yellow core – –
Temperature switch/PTC Red core – –
