Position the cursor on the initialization program (INI) directory. Press the V24
softkey. The initialization program “%_N_INITIAL_INI” is output with the follow-
ing data:
S Global user data
S Option data
S Protection zones
S R parameters
S Setting data
S Machine data
S Tool/magazine data
S Zero offsets
None
– Compensation data (EEC, QEC, CEC)
– Part programs
– Definition data and macros
– Part programs, workpieces, cycles
– PLC programs and data
– Display machine data, drive machine data
If you position the cursor on NC active data and initiate the data output via
V.24, an initialization program %_N_INITIAL_INI is also output, but with all data
stored in the NC active data directory. That is including compensation data.
Output of
initialization
program (INI)
