Detailed description
2.12 Block descriptions
Basic logic functions: PLC Basic program powerline (P3 pl)
Function Manual, 11/2006, 6FC5397-0BP10-2BA0
147
MagNr
From
PlaceNr
From
MagNr
To
PlaceNr
To
Search area
WVar1 WVar2 WVar3 WVar4
#M1 #P1 #M2 #P2 Locations starting at magazine #M1, location #P1 up to
magazine #M2, location #P2 are searched
#M1 -1 #M1 -1 All locations in magazine #M1 - and no others - are
searched
#M1 -1 -1 -1 All locations starting at magazine #M1 are searched
#M1 #P1 -1 -1 All locations starting at magazine #M1 and location
#P1 are searched
#M1 #P1 #M1 -1 Locations in magazine #M1 starting at magazine #M1
and location #P1 in this magazine are searched
#M1 #P1 #M2 -1 Locations starting at magazine #M1, location #P1 up to
magazine #M2, location #P2 are searched
#M1 -1 #M2 #P2 Locations starting at magazine #M1 up to magazine
#M2, and in that location #P2 are searched
#M1 -1 #M2 -1 Locations starting at magazine #M1 up to and including
magazine #M2 are searched
-1 -1 -1 -1 All magazine locations are searched
For a symmetric search (see parameter "SearchDirection")
• the search domain may stretch only over a single magasine (cases 2 and 5 from the table
given above). If another search domain is specified, the service will malfunction.
• a reference location must be specified in the parameters "MagNrRef" and "PlaceNrRef",
with respect to which the symmetric search is done.
The reference location is a buffer location (a location from the magazine buffer, i.e., change
position, gripper, etc.) or a load point (a location from the internal loading magazine). The
search is executed symmetrically with reference to the magazine location before the
specified reference location. A multiple assignment to the magazine being searched must be
configured in the TPM block for the reference location. If this is not the case, a malfunction
occurs. If the magazine location in front of the reference location is outside the search
domain, the service responds as if it has not found a matching location.
Note
Before and after this PI service, the MMCSEM PI service must be called with the associated
parameter "WVar1" for this PI service. See PI service MMCSEM for more information.
