Detailed description
2.12 Block descriptions
Basic logic functions: PLC Basic program powerline (P3 pl)
148 Function Manual, 11/2006, 6FC5397-0BP10-2BA0
Parameterization:
Parameterization
Signal Type Value range Meaning
PIService ANY PI.TSEARC Complex search using search screen forms
Unit INT 1, 2 TOA
WVar1 INT MagNrFrom Magazine number of magazine from which
search must begin
WVar2 INT PlaceNrFrom Location number of location in magazine
MagNrFrom, at which search must begin
WVar3 INT MagNrTo Magazine number of magazine at which search
must end
WVar4 INT PlaceNrTo Location number of location in magazine
MagNrTo, at which search must end
WVar5 INT MagNrRef Magazine number of (internal) magazine, with
reference to which the symmetrical search is to be
performed. (this parameter is only relevant with a
"symmetrical" search direction)
WVar6 INT PlaceNrRef Location number of location in magazine
MagNrRef, with reference to which the symmetrical search
is to be performed. This parameter is only relevant with a
"symmetrical" search direction
WVar7 INT 1, 2, 3 SearchDirection specifies the required search direction.
1: Forwards from the first location of the search domain
2: Backwards from the last location of the search domain
3: Symmetrical with real magazine location positioned in
front of the location specified by MagNrRef and PlaceNrRef
WVar8 INT 0, 1, 2, 3 KindofSearch
0: Find all tool with this property cutting edge specifically
1: Search for the first tool found with this property (cutting
edge specifically)
2: Browse all cutting edges to find all tool with this property
3: Browse all tools to search for the first tool found with this
property
