Detailed description
2.12 Block descriptions
Basic logic functions: PLC basic program solution line (P3 sl)
Function Manual, 11/2006, 6FC5397-0BP10-2BA0
133
PI service: CRCEDN
Create new cutting edge:
If the T number of an existing tool is specified in parameter “T number” in the PI service, then
a cutting edge is set up for this particular tool (in this case, parameter “D number” (number of
cutting edge to be created) has a value range of 00001–00009). If a positive T number is
specified as a parameter and the tool for the T number entered does not exist, then the PI
service is aborted. If a value of 00000 is entered for the T number (model of absolute D
numbers), then the D number value range might extend from 00001 to 31999. The new
cutting edge is set up with the specified D number. If the specified cutting edge already
exists, then the PI service is aborted in both cases.
Parameterization
Signal Type Range of values Significance
PIService ANY PI.CRCEDN Create new cutting edge
Unit INT 1 - 10 TOA
WVar1 INT T number of tool for which cutting
edge must be created. A setting of
00000 states that the cutting edge
should not refer to any particular tool
(absolute D number).
WVar2 INT 1 - 9 or
01 - 31999
Edge number of tool cutting edge
PI service: CREACE
Function Create tool cutting edge:
Creation of the cutting edge with the next higher/next unassigned D number for the tool with
the transferred T number in TO, TS (if present). The cutting edge for the OEM cutting edge
data is set up simultaneously in the TUE block - if one is present.
Parameterization
Signal Type Range of values Significance
PIService ANY PI.CREACE Create cutting edge
Unit INT 1 - 10 TOA
WVar1 INT T number
