Scale parameters and functions of the belt scale
8.11 DR 9 module information
SIWAREX WP241
106 Manual, 04/2014, A5E33713528A
8.11
DR 9 module information
No entries can be made in data record DR 9. This data record provides information on the
inner workings of the SIWAREX module. This information is used to identify the module at
the manufacturer plant (e.g. in the event of repairs). The entries in the data record are of no
importance to the user for operation.
Table 8- 9 Assignment of data record 9
Variable
Note
Type
L
Rw
Default
Min.
Max.
Register
Data record number
Contains no. of data record
USHORT
2
r
9
-
-
1351
Length
Data record length information
USHORT
2
r
68
-
-
1352
Application Information about which application
the DR belongs to
USHORT 2 r 104 - - 1353
Version identifier Information about current data record
version
USHORT 2 r 1 1 65635 1354
Order No. - header Maximum and current string length
for the order number
UBYTE[2] 2 r 16.16 - - 1355
Order No. Order number of the module
7MH ..
CHAR[16] 16 r "7MH …" - - 1356
Serial number -
header
String header UBYTE[2] 2 r 12.12 - - 1364
Serial number
Serial number " XXX00001"
CHAR[12]
12
r
-
-
1365
Firmware type -
header
String header UBYTE[2] 2 r 2.2 - - 1371
Firmware type
Character V - Release B - Test etc.
CHAR[2]
2
r
'V '
-
-
1372
Firmware version -
1st position
Version 1. USHORT 2 r 0 - - 1373
Firmware version -
2nd position
Version 2. USHORT 2 r 0 - - 1374
Firmware version -
3rd position
Version 3. USHORT 2 r 0 - - 1375
Hardware version
number
ES hardware version number
(e.g. 03)
USHORT 2 r 1 - - 1376
OS version header
String header
UBYTE[2]
2
r
1.1
-
-
1377
OS version (loader)
- designation
Character V - Release B - Test etc. CHAR[2] 2 r 'V ' - - 1378
OS version (loader)
- designation
e.g. version n USHORT 2 r 'V ' - - 1379
DRAM memory
Flash memory
USHORT
2
r
0
-
-
1380
Flash memory
MRAM memory
USHORT
2
r
0
-
-
1381
MRAM memory
Memory type
USHORT
2
r
0
-
-
1382
Reserve 1
0
FLOAT
4
r
0
-
-
1383
