Siemens SIWAREX WP241 User Manual

Scale parameters and functions of the belt scale
8.14 DR 13 RS485 parameters
SIWAREX WP241
Manual, 04/2014, A5E33713528A
111
8.14
DR 13 RS485 parameters
The parameters which define the response of the RS485 interface are specified in data
record DR 13. If the interface is not used, the default values can be retained.
Procedure
● Check the parameters and modify them as required
● Transfer the data record to the scale
Table 8- 12 Assignment of data record 13
Variable
Note
Type
L
Rw
Default
Min.
Max.
Register
Data record
number
Contains no. of data record USHORT 2 r 13 - - 1558
Length
Data record length information
USHORT
2
r
24
-
-
1559
Application Information about which application
the data record belongs to
USHORT 2 r 104 - - 1560
Version identifier Information about current data record
version
USHORT 2 r 1 1 65635 1561
RS485 protocol
(Page 112)
0: No protocol
1: MODBUS RTU
USHORT 2 rw 1 0 2 1562
RS485 baud rate
(Page 112)
2: 9 600 bps
3: 19 200 bps
4: 38 400 bps
5: 57 600 bps
6:115 000 bps
USHORT 2 rw 3 0 6 1563
RS485 character
parity (Page 112)
Character parity
0: Even
1: Odd
BIT 0 rw 0 0 1 1564.16
RS485 number of
data bits
(Page 113)
Number of data bits per character
0: 7 data bits
1: 8 data bits
BIT 0 rw 0 0 1 1564.15
RS485 number of
stop bits
(Page 113)
Number of stop bits
0: 1 stop bit
1: 2 stop bits
BIT 0 rw 0 0 1 1564.14
Bit 3
Reserve
BIT
0
rw
0
0
1
1564.13
Bit 4
Reserve
BIT
0
rw
0
0
1
1564.12
Bit 5
Reserve
BIT
0
rw
0
0
1
1564.11
Bit 6
Reserve
BIT
0
rw
0
0
1
1564.10
Bit 7
Reserve
BIT
0
rw
0
0
1
1564.9
Bit 8
Reserve
BIT
0
rw
0
0
1
1564.8
Bit 9
Reserve
BIT
0
rw
0
0
1
1564.7
Bit 10
Reserve
BIT
0
rw
0
0
1
1564.6
Bit 11
Reserve
BIT
0
rw
0
0
1
1564.5
Bit 12
Reserve
BIT
0
rw
0
0
1
1564.4
Bit 13 Reserve BIT 0 rw 0 0 1 1564.3
