Communication
11.1 Integration in SIMATIC S7-1200
SIWAREX WP241
154 Manual, 04/2014, A5E33713528A
Creating the hardware configuration
Starting with TIA Portal V13, the SIWAREX WP241 is integrated as standard in the hardware
profile as an S7-1200 technology module.
For TIA Portal V12 SP1, an HSP is available as download from the Siemens Customer
Support.
Figure 11-1 Configuration in the TIA Portal "HW catalog"
The module can be positioned directly next to the S7-1200 CPU using drag and drop.
Figure 11-2 Configuration with S7-1212 CPU
