Siemens SIWAREX WP241 User Manual

Scale parameters and functions of the belt scale
8.19 DR 19 External speed
SIWAREX WP241
Manual, 04/2014, A5E33713528A
119
8.19
DR 19 External speed
If the SIWAREX module is not to determine the belt speed because the current speed is
available externally, e.g. in a controller, it can be passed on to the SIWAREX via DR 19. The
current material flow rate can then be calculated.
Procedure
● Enter a value in data record DR 19
● Transfer the data record to the scale
Table 8- 17 Assignment of data record 19
Variable
Note
Type
L
Rw
Default
Min.
Max.
Register
Data record
number
Contains no. of data record USHORT 2 r 19 - - 1602
Length
Data record length information
USHORT
2
r
16
-
-
1603
Application Information about which application the
data record belongs to
USHORT 2 r 104 - - 1604
Version identifier Information about current data record
version
USHORT 2 r 1 1 65635 1605
External speed
value
The externally determined speed can be
sent to the scale.
FLOAT 4 rw 0 - - 1606
Reserve 1
Reserve
SHORT
2
rw
0
0
-
1608
Reserve 2
Reserve
USHORT
2
rw
0
0
-
1609
