SIWAREX WP241

Manual, 04/2014, A5E33713528A

Connecting

6.1

Overview

All external connections (with the exception of the Ethernet interface) are made by means of

the screw connectors (terminal block 1 to 4).

①

24 V connection

⑥

Digital input connection

②

Analog output connection

⑦

Ethernet interface connection

③

Load cell connection

⑧

Calibration bridge connection

④

RS485 interface connection

⑨

Mounting terminals for the calibration

protection plate

⑤

Digital output connection

Figure 6-1 SIWAREX WP241 connection areas
