Communication
11.2 Communication via Modbus
SIWAREX WP241
162 Manual, 04/2014, A5E33713528A
The following baud rates can be set:
● 9 600 bit/s
● 19 200 bit/s (default setting)
● 38 400 bit/s
● 57 600 bit/s
● 115 000 bit/s
Functions which can be used by the master are listed below. The structure and contents of
the registers are shown in chapter "Scale parameters and functions of the belt scale
(Page 69)".
Service
Function code
Usage
Read Holding Registers
03
Read one or more 16-bit parameter registers
Write Single Register
06
Write a single parameter register
Write Multiple Registers
16
Write multiple registers
If a request of the master is answered by the SIWAREX module (slave), the SIWAREX
module sends a response frame with or without errors. In the case of a response without
error message, the response frame contains the received function code; in the case of
errors, the highest bit of the function code is set. This corresponds to the Modbus standard.
Afterwards, the master requests the data record DR 32 to check which process-related data
or operator errors exist.
11.2.3
Data record concept
The register assignment is an image of the data records. The chapter → Scale parameters
and functions of the belt scale (Page 69) describes the data records, variables and functions,
including the register addresses. The data records are always checked as complete data
packets for plausibility. For this reason, you must follow a specific procedure to change
individual parameters.
