Scale parameters and functions of the belt scale
8.14 DR 13 RS485 parameters
SIWAREX WP241
112 Manual, 04/2014, A5E33713528A
Variable
Note
Type
L
Rw
Default
Min.
Max.
Register
Bit 14
Reserve
BIT
0
rw
0
0
1
1564.2
Bit 15
Reserve
BIT
2
rw
0
0
1
1564.1
RS485 Modbus
address
(Page 113)
MODBUS address USHORT 2 rw 20 1 255 1565
Reserve
SHORT
2
rw
0
-
-
1566
Modbus RTU
response delay
(Page 113)
Delay time for response with MODBUS
RTU in ms (RS485)
USHORT 2 rw 0 - - 1567
Reserve
Reserve
FLOAT
4
rw
0
-
-
1568
8.14.1
RS485 protocol
This parameter defines the protocol for communication via the RS485 interface.
Value
Protocol
0
No communication/protocol
1
Modbus RTU
8.14.2
RS485 baud rate
This parameter defines the baud rate for the RS485 interface.
Value
Baud rate
2
9 600 bps
3
19 200 bps
4
38 400 bps
5
57 600 bps
6
115 000 bps
8.14.3
RS485 character parity
This parameter defines the character parity for the RS485 interface.
Value
Character parity
0
Even
1
Odd
