Scale parameters and functions of the belt scale
8.16 DR 16 Simulation (belt speed and belt load)
SIWAREX WP241
Manual, 04/2014, A5E33713528A
115
8.16
DR 16 Simulation (belt speed and belt load)
The belt load and belt speed can be simulated using an input via data record DR 16. The
SIWAREX module must first be released for simulation mode in DR 3 and then activated
with command 3 or 5 or deactivated with command 4 or 6.
Procedure
● Release simulation mode in DR 3
● Send command no. 3 and/or 5 to the SIWAREX module
● Enter the belt load and/or speed to be simulated
● Transfer the data record to the SIWAREX module
Table 8- 14 Assignment of data record 16
Variable
Note
Type
L
Rw
Default
Min.
Max.
Register
Data record number
Contains no. of data record
USHORT
2
r
16
-
-
1578
Length Data record length
information
USHORT 2 r 20 - - 1579
Application Information about which
application the data record
belongs to
USHORT 2 r 104 - - 1580
Version identifier Information about current
data record version
USHORT 2 r 1 1 65635 1581
Value for belt load
simulation (Page 115)
FLOAT 4 rw 0 - - 1582
Value for belt speed
simulation (Page 115)
SHORT 2 rw 0 0 - 1584
Reserve
Reserve
USHORT
2
rw
0
0
-
1586
Reserve
USHORT
2
rw
0
0
-
1587
8.16.1
Value for belt load simulation
Only use values for the belt load which are within the measuring range of the scale. The
word "TEST" is displayed on the main display during simulation and a status bit is set.
8.16.2
Value for belt speed simulation
Only use values for simulation of the belt speed which are within the speed range of the belt.
The word "TEST" is displayed on the main display during simulation and a status bit is set.
