Siemens SIWAREX WP241 User Manual

Scale parameters and functions of the belt scale
8.23 DR 31 Process state extended
SIWAREX WP241
128 Manual, 04/2014, A5E33713528A
Variable
Note
Type
L
Rw
Default
Min
.
Max.
Register
Current status of
input .2
Current status of input .0 BIT 0 r 0 0 1 3322.14
Current status of
input .3
Current status of input .0 BIT 0 r 0 0 1 3322.13
Bit 4
Reserve
BIT
0
r
0
0
1
3322.12
Bit 5
Reserve
BIT
0
r
0
0
1
3322.11
Bit 6
Position of DIP switch 1
BIT
0
r
0
0
1
3322.10
Bit 7
Position of DIP switch 2
BIT
0
r
0
0
1
3322.9
Current status of
output .0
Current status of output .0 BIT 0 r 0 0 1 3322.8
Current status of
output .1
Current status of output .1 BIT 0 r 0 0 1 3322.7
Current status of
output .2
Current status of output .2 BIT 0 r 0 0 1 3322.6
Current status of
output .3
Current status of output .3 BIT 0 r 0 0 1 3322.5
Reserve BIT 0 r 0 0 1 3322.4
Reserve
BIT
0
r
0
0
1
3322.3
Reserve BIT 0 r 0 0 1 3322.2
Reserve
BIT
2
r
0
0
1
3322.1
Nominal boat load
(Page 129)
Is imported from DR 4 if the parameters
have been imported from DR 4 into DR
3.
FLOAT 4 r 0 0 3323
Refresh counter for
process values
(Page 129)
Refresh counter incremented by 1 if
weight values were changed
USHORT 2 r 0 - - 3325
Reserve
USHORT
2
r
0
-
-
3326
8.23.1
Unfiltered digit value
The unfiltered digit value (measurement of weight) is the internal measured value
immediately before filtering.
8.23.2
Filtered digit value
The filtered digit value (measurement of weight) is the internal measured value immediately
after filtering.
8.23.3
Current load cell signal (mV)
The current input voltage of the load cell(s) in mV.
