Scale parameters and functions of the belt scale
8.9 DR 7 Process interfaces
SIWAREX WP241
100 Manual, 04/2014, A5E33713528A
8.9.1
Assignment digital input DI 0, 1, 2, 3
A command trigger can be assigned to a digital input. This is done on the basis of the
command number: → Command lists (Page 147).
Assignment input DI.0, 1, 2, 3:
Code
Assignment
0
Not assigned
n
Command code is triggered at a rising edge (1->0 transition)
1304 (only DI .0)
The speed sensor is connected (up to approx. 5 kHz)
1303 (only DI .0)
Message to SIWAREX "Belt switched on"
75 (only DI .1) Belt revolution sensor for calculation of belt for exact triggering of revolution
time
8.9.2
Input filtering (hardware setting)
To ensure that the inputs do not respond too quickly to the signal change, a minimum signal
pending time can be specified. The pending signal is not processed further until this time has
elapsed.
The following values can be set:
Value
Signal pending period
Value
Signal pending period
0
0.2 ms
4
1.6 ms
1
0.2 ms
5
3.2 ms
2
0.4 ms
6
6.4 ms
3 0.8 ms 7 12.8 ms
8.9.3
Assignment digital output DQ 0, 1, 2, 3
A status display can be assigned to a digital input. This is done on the basis of the bit
number.
Assignment output DQ.0, 1, 2, 3:
Code Hex
Status display
Code 255
Output is not active
0 … 31
Bit no. of the status flags from bytes 0 to 3 (DR 30)
100 … 131
Bit no. of the status flags from bytes 0 to 3 (DR 30), but inverted
33
Controlled via data record 18
34
Controlled via S7 I/O modules
