Scale parameters and functions of the belt scale
8.9 DR 7 Process interfaces
SIWAREX WP241
Manual, 04/2014, A5E33713528A
99
Variable
Note
Type
L
Rw
Default
Min.
Max.
Register
Response of
analog output to
faults or SIMATIC
STOP (Page 102)
0: Switch off
1: retain function
2: Output configured output value
3: Output maximum value (24 mA,
NAMUR)
USHORT 2 rw 0 0 3 1326
Start value for the
analog output
(Page 102)
Value at which 0 …4 mA is to be
output
FLOAT 4 rw 0 max.
weigh.
range
max.
weigh.
range
1327
End value for the
analog output
(Page 103)
Value at which 20 mA is to be output FLOAT 4 rw 0 max.
weigh.
range
max.
weigh.
range
1329
Output value
following fault or
SIMATIC STOP
(Page 103)
Value to be output when the OutDis
signal is enabled (in mA)
FLOAT 4 rw 0 0 24 1331
Trace recording
cycle (Page 103)
1: 10 ms
10: 100 ms
100: 1 s
1 000: 10 s
USHORT 2 rw 1 1 1000 1333
Trace storage
method (Page 103)
0: Trace recording runs as a circular
buffer
1: Trace is stopped when the trace
memory is full
BIT 0 rw 0 0 1 1334.16
Bit 1
Reserve
BIT
0
rw
0
0
1
1334.15
Bit 2
Reserve
BIT
0
rw
0
0
1
1334.14
Bit 3
Reserve
BIT
0
rw
0
0
1
1334.13
Bit 4
Reserve
BIT
0
rw
0
0
1
1334.12
Bit 5
Reserve
BIT
0
rw
0
0
1
1334.11
Bit 6
Reserve
BIT
0
rw
0
0
1
1334.10
Bit 7
Reserve
BIT
1
rw
0
0
1
1334.9
Bit 8
Reserve
BIT
0
rw
0
0
1
1334.8
Bit 9
Reserve
BIT
0
rw
0
0
1
1334.7
Bit 10
Reserve
BIT
0
rw
0
0
1
1334.6
Bit 11
Reserve
BIT
0
rw
0
0
1
1334.5
Bit 12
Reserve
BIT
0
rw
0
0
1
1334.4
Bit 13
Reserve
BIT
0
rw
0
0
1
1334.3
Bit 14
Reserve
BIT
0
rw
0
0
1
1334.2
Bit 15
Reserve
BIT
1
rw
0
0
1
1334.1
Load per pulse
(Page 104)
External totalizer - amount per pulse:
output of pulses for external totalizer
REAL 4 rw 0 0 1335
Pulse duration in ms (output of pulses
for external totalizers)
LONG 4 rw 0 0 1337
Reserve
LONG
4
rw
0
0
1339
