Siemens SIWAREX WP241 User Manual

Scale parameters and functions of the belt scale
8.9 DR 7 Process interfaces
SIWAREX WP241
98 Manual, 04/2014, A5E33713528A
Variable
Note
Type
L
Rw
Default
Min.
Max.
Register
Assignment of digital output .1
(see output .0)
USHORT 2 rw 0 0 0xFFFF 1319
Assignment of digital output .2
(see output .0)
USHORT 2 rw 0 0 0xFFFF 1320
Assignment of digital output .3
(see output .0)
USHORT 2 rw 0 0 0xFFFF 1321
Response of digital
outputs to faults or
SIMATIC STOP
(Page 101)
Response of digital outputs following
module fault or CPU STOP:
0: Outputs are switched off
1: Outputs are not switched off,
continue
2: The relevant substitute value is
activated
3: The outputs are switched on
USHORT 2 rw 0 0 0 1322
Substitute value for
DQ 0, 1, 2, 3
following fault or
SIMATIC STOP
(Page 101)
Substitute value for DQ.0 following
fault or SIMATIC CPU STOP
BIT 0 rw 0 0 1 1323.16
Substitute value for DQ.1 following
fault or SIMATIC CPU STOP
BIT 0 rw 0 0 1 1323.15
Substitute value for DQ.2 following
fault or SIMATIC CPU STOP
BIT 0 rw 0 0 1 1323.14
Substitute value for DQ.3 following
fault or SIMATIC CPU STOP
BIT 0 rw 0 0 1 1323.13
Bit 4
Reserve
BIT
0
rw
0
0
1
1323.12
Bit 5
Reserve
BIT
0
rw
0
0
1
1323.11
Bit 6
Reserve
BIT
0
rw
0
0
1
1323.10
Bit 7
Reserve
BIT
0
rw
0
0
1
1323.9
Bit 8
Reserve
BIT
0
rw
0
0
1
1323.8
Bit 9
Reserve
BIT
0
rw
0
0
1
1323.7
Bit 10
Reserve
BIT
0
rw
0
0
1
1323.6
Bit 11
Reserve
BIT
0
rw
0
0
1
1323.5
Bit 12
Reserve
BIT
0
rw
0
0
1
1323.4
Bit 13
Reserve
BIT
0
rw
0
0
1
1323.3
Bit 14
Reserve
BIT
0
rw
0
0
1
1323.2
Bit 15 Reserve BIT 2 rw 0 0 1 1323.1
Analog output
range (Page 102)
0: 0 … 20 mA
1: 4 … 20 mA
USHORT 2 rw 0 0 1 1324
Analog output
source (Page 102)
Basis of analog value output:
0 = belt speed
1 = belt load
2 = material flow rate
3 = ext. specification DS17
4 = ext. specification S7 interface
USHORT 2 rw 2 0 3 1325
