Siemens SIWAREX WP241 User Manual

Scale parameters and functions of the belt scale
8.26 DR 34 ASCII main display value
SIWAREX WP241
Manual, 04/2014, A5E33713528A
135
8.26
DR 34 ASCII main display value
The ASCII display value corresponds to the value on the scale's main display. The content
can be controlled using display commands.
Table 8- 24 Assignment of data record 34
Variable
Note
Type
L
Rw
Default
Min.
Max.
Register
Data record number
Contains no. of data record
USHORT
2
r
34
-
-
4000
Length
Data record length information
USHORT
2
r
26
-
-
4001
Application
Information about which application
the DR belongs to
USHORT 2 r 104 - - 4002
Version identifier Information about current data
record version
USHORT 2 r 1 1 65635 4003
ASCII display string
header
Maximum length and actual length
of string
UBYTE[2] 2 r 16.2 - - 4004
Content of main
display as ASCII
string (Page 135)
For display of the material flow
rate, belt load, speed, totals
CHAR[16] 16 r " " - - 4005
8.26.1
Content of main display as ASCII string
Commands are used to toggle the display.
The following values can be displayed in belt scale applications:
Value
Command
Material flow rate
710
Weight
715
Flow rate in %
735
Belt load
740
Belt load in % 745
Speed
760
Speed in %
765
Accumulated total
771
Main total
772
Totalizer S3
773
Totalizer S4
774
Totalizer S5
775
Totalizer S6
776
Official calibration
801
Serial number
871
Firmware version
875
