Siemens SIWAREX WP241 User Manual

Scale parameters and functions of the belt scale
8.27 DR 38 Process state extended
SIWAREX WP241
136 Manual, 04/2014, A5E33713528A
8.27
DR 38 Process state extended
The data record contains scale-specific parameters.
Procedure
● Read data record DR 38
● Display/analyze the required tags
Table 8- 25 Assignment of data record 38
Variable
Note
Type
L
Rw
Default
Min.
Max.
Register
Data record number
Contains no. of data record
USHORT
2
r
38
-
-
4500
Length Data record length
information
USHORT 2 r 64 - - 4501
Application Information about which
application the data record
belongs to
USHORT 2 r 104 - - 4502
Version identifier Information about current
data record version
USHORT 2 r 1 1 65635 4503
Counter zeroing Number of implemented
zeroing procedures, recording
of manual and automatic
zeroing procedures (is reset
when loading the factory
settings)
ULONG 4 r 0 4504
Counter initial zero
calibration
Number of implemented initial
zero calibration procedures
(is reset when loading the
factory settings)
ULONG 4 r 0 4506
Counter span calibration Number of implemented span
calibration procedures (is
reset when loading the factory
settings)
ULONG 4 r 0 4508
Drag indicator (belt load) Maximum belt load that has
occurred
FLOAT 4 r 0 4510
Reserve
LONG
4
r
0
4512
Current initial zero offset
(belt load)
Current deviation from
original zero (when loaded)
FLOAT 4 r 0 4514
Current initial zero offset
(in % of nominal load)
Current deviation from
original zero (in % of nominal
load)
FLOAT 4 r 0 4516
Reserve
FLOAT
4
r
0
4518
Reserve
LONG
4
r
0
4520
Reserve
LONG
4
r
0
4522
Reserve
LONG
4
r
0
4524
Reserve
3xLONG
LONG
12
0
4526
