8.9 DR 7 Process interfaces
SIWAREX WP241
Manual, 04/2014, A5E33713528A
97
8.9
DR 7 Process interfaces
Data record DR 7 contains the parameters for defining the properties of the available I/O
modules (digital inputs, digital outputs, analog output, serial ports).
If a port is not used, the default value can be retained.
Procedure
● Change the parameters if necessary
● Transfer the data record to the scale
Table 8- 5 Assignment of data record 7
Variable
Note
Type
L
Rw
Default
Min.
Max.
Register
Data record
number
Contains no. of data record USHORT 2 r 7 - - 1309
Length
Data record length information
USHORT
2
r
64
-
-
1310
Application Information about which application
the DR belongs to
USHORT 2 r 104 - - 1311
Version identifier Information about current data record
version
USHORT 2 r 1 1 65635 1312
Assignment digital
input DI 0, 1, 2, 3
(Page 100)
Assignment of digital input .0
Code 0: No command assigned
1 … n: command number, is triggered
at a rising edge (0->1 transition), 1304
pulse sensor
USHORT 2 rw 0 0 1999 1313
Assignment of digital input .1
Code 0: No command assigned
1 … n: command number, is triggered
at a rising edge (0->1 transition)
USHORT 2 rw 0 0 1999 1314
Assignment of digital input .2
Code 0: No command assigned
1 … n: command number, is triggered
at a rising edge (0->1 transition)
USHORT 2 rw 0 0 1999 1315
Assignment of digital input .3
Code 0: No command assigned
1 … n: command number, is triggered
at a rising edge (0->1 transition)
USHORT 2 rw 0 0 1999 1316
Input filtering
(hardware setting)
(Page 100)
0: 0.2 ms
1: 0.2 ms
2: 0.4 ms
3: 0.8 ms
4: 1.6 ms
5: 3.2 ms
6: 6.4 ms
7: 12.8 ms
USHORT 2 rw 5 0 7 1317
Assignment digital
output DQ 0, 1, 2,
3 (Page 100)
Assignment of digital output .0
100…131: Bit no. of the status flags
from bytes 0 to 3 (DR 30), but inverted
33: data record 18
34: S7 I/O modules
USHORT 2 rw 0 0 0xFFFF 1318
