Scale parameters and functions of the belt scale
8.25 DR 33 Totalizers
SIWAREX WP241
Manual, 04/2014, A5E33713528A
133
8.25
DR 33 Totalizers
Data record DR 33 contains the actual values of the totalizers.
Totalizing becomes active when the minimum belt load for the totalizer (parameter in DR6)
has been exceeded. Command 652 can be used to stop all totalizers except S6. Command
651 starts totalizing again.
Table 8- 23 Assignment of data record 33
Variable
Note
Type
L
Rw
Default
Min.
Max.
Register
Data record
number
Contains no. of data record USHORT 2 r 33 - 3514
Length
Data record length information
USHORT
2
r
44
-
3515
Application Information about which application the
data record belongs to
USHORT 2 r 104 - 3516
Version identifier Information about current data record
version
USHORT 2 r 1 3517
Current master
totalizer (S1)
(Page 134)
Master totalizer (S1) since commissioning
of the scale
DOUBLE 8 r 0 3518
Current main
totalizer (S2)
(Page 134)
Current main totalizer (S2) FLOAT 4 r 0 3522
Reserve
-
FLOAT
4
r
0
3524
Totalizer 3 (S3),
totalizer 4 (S4),
totalizer 5 (S5)
(Page 134)
Totalizer S3
FLOAT
4
r
0
3526
Totalizer S4 FLOAT 4 r 0 3528
Totalizer S5 FLOAT 4 r 0 3530
Totalizer 6 (S6)
(Page 134)
Totalizer S6 FLOAT 4 r 0 3532
Reserve
-
FLOAT
4
r
0
3534
