Scale parameters and functions of the belt scale
8.6 DR 4 Temporary parameters
SIWAREX WP241
Manual, 04/2014, A5E33713528A
87
8.6
DR 4 Temporary parameters
Data record DR 4 temporarily displays the results of the calibration commands. You can
decide if you wish to apply the results and transfer them to the parameter set in DR 3. The
new calibration results become effective following importing into the parameter set. The
temporary parameters are not saved powerfail-proof.
This data record cannot be sent to the scale.
Table 8- 2 Assignment of data record 4
Variable
Note
Type
L
Rw
Default
Min.
Max.
Register
Data record number
Contains no. of data record
USHORT
2
r
4
-
-
1200
Length
Data record length information
USHORT
2
r
88
-
-
1201
Application
Information about which application
the DR belongs to
USHORT 2 r 104 - - 1202
Version identifier Information about current data
record version
USHORT 2 r 1 1 65635 1203
Vmax. Speed (belt
empty)
Determination using the "Start/Stop
belt revolution detection"
commands with empty belt
Command for importing: "Apply
(nominal) speed" (85)
FLOAT 4 r 0 1204
Speed correction if belt
loaded
Only relevant if a sensor is not
present, determination using the
"Start/Stop belt revolution
detection" commands with empty
belt
Command for importing: "Apply
speed parameters "belt loaded""
(86)
FLOAT 4 r 0 1206
Belt load factor for the
speed correction
Only relevant if a sensor is not
present, determination using the
"Start/Stop belt revolution
detection" commands with empty
belt
Command for importing: "Apply
speed parameters "belt loaded""
(86)
FLOAT 4 r 0 1208
Impulse constant
speed sensor
Impulses per length unit (length
unit from belt load),
Determination using the "Start/Stop
belt revolution detection"
commands with empty belt
Command for importing: "Apply
pulse parameter" (87)
LONG 4 r 0 1210
Pulses per belt
revolution
Pulses for one belt revolution,
determination with empty belt using
"Start/Stop belt revolution
detection" commands
Command for importing: "Apply
pulse parameter" (87)
LONG 4 r 0 1212
