Siemens SIWAREX WP241 User Manual

Scale parameters and functions of the belt scale
8.6 DR 4 Temporary parameters
SIWAREX WP241
88 Manual, 04/2014, A5E33713528A
Variable
Note
Type
L
Rw
Default
Min.
Max.
Register
Pulses per second at
nominal speed (Vmax)
Determination using the "Start/Stop
belt revolution detection"
commands with empty belt
Command for importing: "Apply
pulse parameter" (87)
LONG 4 r 0 1214
Reserve
LONG
4
r
0
1216
Reserve
LONG
4
r
0
1218
Reserve
LONG
4
r
0
1220
Initial zero calibration
digits
Measure mean value following
calibration command "Start initial
zero calibration".
Command for importing: "Apply
initial zero calibration digits" (88)
LONG 4 r 0 1222
Deviation from old
initial zero calibration
digits (%)
Is calculated following
determination of zero calibration
digits
FLOAT 4 r 0 1224
Calibration weight
(calculated)
Determine from the automatic
calibration or from the weight
calibration or from the load
calibration or from the amount of
material
Command for importing: "Apply
span calibration digits" (89)
FLOAT 4 r 0 1226
Calibration load
(calculated)
Measure mean value FLOAT 4 r 0 1228
Span calibration digits Measure mean value following
calibration commands
LONG 4 r 0 1230
Deviation from old
span calibration digits
(%)
Is calculated following
determination of span calibration
digits
FLOAT 4 r 0 1232
Nominal belt load
(calculated)
Design flow rate / design speed FLOAT 4 r 0 1234
Deviation from old
nominal belt load (%)
Is calculated from the nominal
power, nominal speed, and weigh
length.
FLOAT 4 r 0 1236
Stop watch (Page 89) Start/Stop via command or with
zeroing or calibration commands
LONG 4 r 0 1238
Result calculator
(Page 89)
Calculation in accordance with
multiply a*b or divide a/b
command.
a and b are specified in DR21
FLOAT 4 r 0 1240
Reserve
LONG
4
r
0
1242
