Siemens SIWAREX WP241 User Manual

Scale parameters and functions of the belt scale
8.12 DR 10 load cell parameters
SIWAREX WP241
Manual, 04/2014, A5E33713528A
107
8.12
DR 10 load cell parameters
The parameters of the analog load cells must be checked prior to the automatic calibration
and modified if necessary. Only the parameters identified by bold font and asterisk (*) need
be entered.
Procedure
● Check the parameters and modify them as required
● Transfer the data record to the scale
● Calibrate the scale
Table 8- 10 Assignment of data record 10
Variable
Note
Type
L
Rw
Default
Min.
Max.
Register
Data record number
Contains no. of data record
USHORT
2
r
10
-
-
1400
Length Data record length
information
USHORT 2 r 38 - - 1401
Application Information about which
application the DR belongs
to
USHORT 2 r 104 - - 1402
Version identifier Information about current
data record version
USHORT 2 r 1 1 65635 1403
Number of load cells
(Page 108)
1)
Number of analog load cells USHORT 2 rw 1 1 6 1404
50/60 Hz toggling
(Page 108)
50/60 Hz toggling USHORT 2 rw 0 0 1 1405
Reserve 1
Reserve
USHORT
2
rw
0
0
0
1406
Load cell characteristic
value (Page 108)
1)
Characteristic value of the
load cell (n) [mV/V], the
mean value is used if there
is more than one cell.
FLOAT 4 rw 2 > 0.1 10 1407
Rated load of a load
cell (Page 108)
1)
Rated load of a load cell FLOAT 4 rw 60 - - 1409
Reserve
Reserve
FLOAT
4
rw
0
-
-
1411
Reserve
Reserve
FLOAT
4
rw
0
-
-
1413
Reserve 2
Reserve
SHORT
2
rw
0
-
-
1415
Reserve 3
Reserve
USHORT
2
rw
0
-
-
1416
Reserve 4
Reserve
FLOAT
4
rw
0
-
-
1417
1)
Parameter for calculation of calibration points with theoretical calibration
