Scale parameters and functions of the belt scale
8.8 DR 6 Limits
SIWAREX WP241
92 Manual, 04/2014, A5E33713528A
Various limits are parameterized in data record DR 6. The factory-set parameters
correspond to the typical settings.
● Read the current parameters from the SIWAREX module (receive)
● Check all parameters and modify them as required
● Transfer the data record to the SIWAREX module (send)
Table 8- 4 Assignment of data record 6
Contains no. of data record
Data record length information
Application Information about which
application the DR belongs to
USHORT 2 r 104 - - 1266
Version identifier Information about current data
USHORT 2 r 1 1 65635 1267
Negative and positive
zero offset in %
(Page 94)
Negative range of zero adjuster
referred to the originally
calibrated zero point.
Specification in % of maximum
FLOAT 4 rw 1 0 100 1268
Positive range of zero adjuster
referred to the originally
calibrated zero point.
Specification in % of maximum
FLOAT 4 rw 3 0 100 1270
Smallest totalized
value (Page 94)
Smallest totalized value which
may be recorded with verification
capability
FLOAT 4 rw 0 0 1272
Minimum flow rate
Min. flow rate in % of design flow
rate (for status display)
FLOAT 4 rw 0 0 200 1274
Maximum flow rate
Max. flow rate in % of design flow
rate (for status display)
FLOAT 4 rw 100 0 200 1276
Delay for flow rate
Delay for output of status display
LONG 4 rw 1 0 1278
Minimum belt speed
(Page 94)
Min. belt speed for status display
'Minimum belt speed violated' in
FLOAT 4 rw 10 0 100 1280
Maximum belt speed
(Page 94)
Max. belt speed for status display
'Maximum belt speed violated' in
FLOAT 4 rw 100 0 200 1282
Delay for belt speed
Delay for output of status display
LONG 4 rw 1 0 1284
Minimum belt load
(Page 95)
Min. belt load for status display
'Minimum belt load violated' in %
of nominal belt load
FLOAT 4 rw 5 0 100 1286
