Scale parameters and functions of the belt scale
8.15 DR 15 belt angle
SIWAREX WP241
114 Manual, 04/2014, A5E33713528A
Data recorder DR 15 is used for an external specification.
● Enter the actual inclination angle of the conveyor belt.
● Transfer the data record to the scale.
Table 8- 13 Assignment of data record 15
Data record
Contains no. of data record USHORT 2 r 15 - - 1570
Data record length information
Application Information about which
application the DR belongs to
USHORT 2 r 104 - - 1572
Version identifier Information about current data
USHORT 2 r 1 1 65635 1573
Current belt angle
Angle of inclination FLOAT 4 rw 0 0 60 1574
Input of the angle is provided for belt scales where the inclination of the belt can be changed
during operation. Calculation of the current belt load is corrected by entering the current
angle.
The input is unnecessary if the inclination is always constant: the influence of the constant
angle is compensated or automatically taken into consideration during the calibration with
weights or test chain.
If the scale is automatically calibrated using the load cell parameters and if the scale is not
installed exactly horizontally, you must subsequently enter the inclination angle of the belt.
The input is made in degrees.
