Scale parameters and functions of the belt scale
8.24 DR 32 display of data and operator errors
SIWAREX WP241
130 Manual, 04/2014, A5E33713528A
DR 32 display of data and operator errors
Data record DR 32 is used for Modbus communication with a Modbus master. If a function
which is used to write to the holding register is completed with an error, the data or operator
error reported can be read from data record DR 32. Messages are displayed for at least
three seconds and do not need to be acknowledged in the SIWAREX module.
Data record DR 32 does not need to be polled upon positive completion of a function for
writing to the SIWAREX register.
Table 8- 22 Assignment of data record 32
Data record
Contains no. of data record USHORT 2 r 32 - - 3500
Data record length information
Application Information about which application the
USHORT 2 r 104 - - 3502
Version identifier Information about current data record
USHORT 2 r 1 1 65635 3503
Data or operating error exists
Command code or data record unknown
5002 Command or data change not possible
because write protection is active
BIT r 0 0 1 3504.14
Leaving calibration mode not possible
5004 Command or data transmission only
available in service mode
BIT r 0 0 1 3504.12
5005 Command or data transmission not
possible because service mode is active
BIT r 0 0 1 3504.11
5006 Command or data transmission not
BIT r 0 0 1 3504.10
5007 Command or data transmission not
possible because module is faulty or ODIS
is active
BIT r 0 0 1 3504.9
5008 Command not possible since memory is
full (concerns the trace function)
BIT r 0 0 1 3504.7
5101 Command is not permissible in this
BIT r 0 0 1 3504.6
5104 Command not possible because range is
BIT r 0 0 1 3504.4
Load cell parameter not plausible
Shifting characteristic not possible
6003 Command cannot be executed since a
similar command is already active
BIT r 0 0 1 3505.4
