Messages
9.5 Message list
SIWAREX WP241
Manual, 04/2014, A5E33713528A
145
Item
Color
Labeling
Function
Line 2
LED 1
LINK
LAN connection exists
LED 2
Rx/Tx
LAN communication active
LED 3
Not used
LED 4
Not used
LED 5
DI.0
Digital input 0 active
LED 6
DI.1
Digital input 1 active
LED 7
DI.2
Digital input 2 active
LED 8
DI.3
Digital input 3 active
LED 9
Not used
LED 10
Not used
LED 11
Rx/Tx
RS485 communication active
LED 12
Not used
LED 13
DQ.0
Digital output 0 active
LED 14
DQ.1
Digital output 1 active
LED 15
DQ.2
Digital output 2 active
LED 16
DQ.3
Digital output 3 active
