Command lists
10.2 Command lists
SIWAREX WP241
150 Manual, 04/2014, A5E33713528A
Command
code
Command Description
85 Apply (nominal) speed The nominal speed determined by the commands 70/71 is copied from DR4 to
DR3.
86 Apply speed parameters
"belt loaded"
The result of the commands 72/73 is copied from DR4 to DR3.
87 Apply pulse parameter The pulse parameters determined by the commands 70/71 are copied from
DR4 to DR3. The command is only used for belt scales with speed sensor.
88 Apply initial zero
calibration digits
The result of commands 60 is copied from DR4 to DR3.
89 Apply span calibration
digits
The result of command 61, 63, 65 or 69 is copied from DR4 to DR3.
Table 10- 2 Commands 450 ... 499: Trace commands
Command
code
Command Description
451
Trace ON
Start trace recording
452
Trace OFF
Stop trace recording
453
Single trace element
Create single trace (current state)
454
Reset trace memory
Delete trace recording memory
Table 10- 3 Commands 700 ... 899: HMI display switchover (DR34 – ASCII display)
Command
code
Command Description
701 Increased resolution Enable increased resolution on the main display and the SecureDisplay (x
10), for duration of 5 s
715 Display weight Displays the weight currently present on the scale
735
Flow rate in %
Displays the current flow rate in % of the design flow rate from DR3
740
Belt load
Displays the current belt load
745
Belt load in %
Displays the current belt load in % of the nominal belt load from DR31
760
Speed
Displays the current belt speed
765
Speed in %
Displays the current belt speed in % of the design speed from DR3
771
Master totalizer S1
Displays the current master totalizer
772
Main totalizer S2
Displays the current main totalizer
773
Total S3
Displays the current totalizer S3
774
Total S4
Displays the current totalizer S4
775
Total S5
Displays the current totalizer S5
776
Total S6
Shows the current totalizer S6
801 Display calibration
regulations
Displays the entered calibration regulations
